AirSpade 5000 Utility Series - 105 cfm with 4 ft Barrel
Part Number:








Couldn't load pickup availability
Safely uncover underground utilities with the AirSpade 5000 Utility Series -- the latest innovation in the AirSpade product line. Featuring an in-line style handle, AirSpade 5000 Utility is designed for air excavation applications where gripping the tool in a vertical position is preferred.
AirSpade 5000 Utility harnesses the power of compressed air by incorporating the high-performance, proprietary AirSpade Supersonic Nozzle. Fabricated from non-sparking bronze, the nozzle generates a laser-like air jet that moves at twice the speed of sound for faster, more effective digging.
Rugged, lightweight aluminum handle features full-size grip opening to accommodate linesman's gloves. Comfortable plastic grip provides thermal protection and a degree of electrical insulation. Dead-man trigger ensures safe operation and trigger guard prevents accidental activation. Integral pressure gauge ensures optimal digging performance. 3/4'' NPT compressed air inlet equipped with 3/4'' swivel-type Universal Coupler.
Screw-on, electrically insulated fiberglass barrel rated to 300kV protects operators from buried, high-voltage utility lines. Brass barrel sleeves and connectors minimize sparking potential. Adjustable, rubber dirt shield deflects soil and debris. Detachable, auxiliary handle included.



- AS 5000 Handle with 3/4'' NPT inlet
- Swivel-type Universal Coupler
- 300kV rated, insulated 4 Ft. fiberglass barrel
- Adjustable, rubber dirt shield
- Non-sparking, bronze Supersonic Nozzle
- Detachable, auxiliary handle
- (1) AS 5000 Handle with swivel-type Universal Coupler
- (1) 300kV rated, insulated 4 Ft. fiberglass barrel with dirt shield
- (1) 105 cfm non-sparking, bronze Supersonic Nozzle
- (1) Detachable, auxiliary handle
- (1) Operations Manual
Part Number | Inlet | Min. Compressor Required (hp) | Soil Excavation Rate (cubic ft/min) | Noise Level (dB) | Flow (cfm) |
Dimensions (L" x W" x H") |
Weight (lbs) |
---|---|---|---|---|---|---|---|
Part Number ASU54105 | Inlet 3/4 | Min. Compressor Required (hp) 23 | Soil Excavation Rate (cubic ft/min) 0.9-1.5 | Noise Level (dB) 120 | Flow (cfm) 105 |
Dimensions (L" x W" x H") 63.5 X 11 X 3.2 |
Weight (lbs) 9 |
Part Number ASU54150 | Inlet 3/4 | Min. Compressor Required (hp) 33 | Soil Excavation Rate (cubic ft/min) 1.2-1.8 | Noise Level (dB) 122 | Flow (cfm) 150 |
Dimensions (L" x W" x H") 63.5 X 11 X 3.2 |
Weight (lbs) 9 |
Part Number ASU54225 | Inlet 3/4 | Min. Compressor Required (hp) 50 | Soil Excavation Rate (cubic ft/min) 1.7-2.3 | Noise Level (dB) 124 | Flow (cfm) 225 |
Dimensions (L" x W" x H") 63.5 X 11 X 3.2 |
Weight (lbs) 9 |
