$1,645.35

Setting a new standard for air excavation tools, the Utility AirSpade 4000 - ASU4105G4 Series harnesses the power of compressed air to safely uncover underground utility lines without harm. AirSpade's high-performance, patented supersonic nozzle generates a laser-like jet that moves at twice the speed of sound for faster, more effective digging. With non-sparking Nickle Aluminum Bronze nozzle, Brass components, electrically insulated 4 Ft. barrel rated to 300kV, and a lightweight, ergonomic handle, the Utility AirSpade 4000 maximizes jobsite safety while minimizing operator fatigue. Aluminum handle features full size grip opening to accommodate linesman's gloves. Dead-man trigger ensures safe operation and trigger guard prevents accidental activation. Retractable stabilizer bar provides superior operator control. Integral pressure gauge ensures optimal digging performance.

COMPRESSED AIR REQUIREMENTS
Minimum compressor size 125 cfm @ 90 psi
(tow behind/truck-mounted/PTO)

Setting a new standard for air excavation tools, the Utility AirSpade 4000 - ASU4150G4 Series harnesses the power of compressed air to safely uncover underground utility lines without harm. AirSpade's high-performance, patented supersonic nozzle generates a laser-like jet that moves at twice the speed of sound for faster, more effective digging. With non-sparking Nickle Aluminum Bronze nozzle, Brass components, electrically insulated 4 Ft. barrel rated to 300kV, and a lightweight, ergonomic handle, the Utility AirSpade 4000 maximizes jobsite safety while minimizing operator fatigue. Aluminum handle features full size grip opening to accommodate linesman's gloves. Dead-man trigger ensures safe operation and trigger guard prevents accidental activation. Retractable stabilizer bar provides superior operator control. Integral pressure gauge ensures optimal digging performance.

COMPRESSED AIR REQUIREMENTS
Minimum compressor size 175-185 cfm @ 90 psi
(tow behind/truck-mounted/PTO)

  • Rugged, ergonomic handle with plastic-coated grip
  • Retractable stabilizer bar and integral air-pressure gauge
  • Dead-man trigger with trigger guard
  • Insulated, 4 Ft. fiberglass barrel rated up to 300kV
  • Non-sparking Brass barrel sleeves and threaded connectors
  • Adjustable, rubber spray shield
  • Non-sparking, Nickle Aluminum Bronze supersonic nozzle; 105 and 150 cfm available
  • Inlet: 3/4 NPT
  • Chicago-style swivel connector
  • (1) Utility AirSpade 4000 Handle
  • (1) 4 Ft. insulated, fiberglass barrel with dirt shield
  • (1) 105 cfm non-sparking bronze supersonic nozzle
Part NumberInlet Connection (in)Min. Compressor Required (hp)Soil Excavation Rate (cubic ft/min)Noise Level (dB)Flow (cfm)DimensionsWeight (lbs)
Part Number ASU4105G4 Inlet Connection (in) 3/4 Min. Compressor Required (hp) 23 Soil Excavation Rate (cubic ft/min) 0.9 - 1.5 Noise Level (dB) 116 Flow (cfm) 105 Dimensions 56.3 x 5.5 x 13.4 Weight (lbs) 10.3
Part Number ASU4150G4 Inlet Connection (in) 3/4 Min. Compressor Required (hp) 33 Soil Excavation Rate (cubic ft/min) 1.2 - 1.8 Noise Level (dB) 122 Flow (cfm) 150 Dimensions 56.3 x 5.5 x 13.4 Weight (lbs) 10.3

PRODUCT AVAILABILITY
Lead time: 2 days

  • Rugged, ergonomic handle with plastic-coated grip
  • Retractable stabilizer bar and integral air-pressure gauge
  • Dead-man trigger with trigger guard
  • Insulated, 4 Ft. fiberglass barrel rated up to 300kV
  • Non-sparking Brass barrel sleeves and threaded connectors
  • Adjustable, rubber spray shield
  • Non-sparking, Nickle Aluminum Bronze supersonic nozzle; 105 and 150 cfm available
  • Inlet: 3/4 NPT
  • Chicago-style swivel connector
  • (1) Utility AirSpade 4000 Handle
  • (1) 4 Ft. insulated, fiberglass barrel with dirt shield
  • (1) 150 cfm non-sparking bronze supersonic nozzle
Part NumberInlet Connection (in)Min. Compressor Required (hp)Soil Excavation Rate (cubic ft/min)Noise Level (dB)Flow (cfm)DimensionsWeight (lbs)
Part Number ASU4105G4 Inlet Connection (in) 3/4 Min. Compressor Required (hp) 23 Soil Excavation Rate (cubic ft/min) 0.9 - 1.5 Noise Level (dB) 116 Flow (cfm) 105 Dimensions 56.3 x 5.5 x 13.4 Weight (lbs) 10.3
Part Number ASU4150G4 Inlet Connection (in) 3/4 Min. Compressor Required (hp) 33 Soil Excavation Rate (cubic ft/min) 1.2 - 1.8 Noise Level (dB) 122 Flow (cfm) 150 Dimensions 56.3 x 5.5 x 13.4 Weight (lbs) 10.3

PRODUCT AVAILABILITY
Lead time: 2 days
